1. To enter Engineering Mode, hold the INCLINE DOWN and SPEED DOWN keys for three seconds until Manager Mode appears on the middle LED dis-
play.
2. Press any UP arrow key and Engineering Mode will appear on the display.
3. Press ENTER once Engineering Mode is displayed.
4. To scroll between programs in the Engineering Mode, press any UP or DOWN arrow key.
5. Press ENTER to modify the program settings once displayed.
6. Press any UP or DOWN arrow key to change value.
7. Once program setting is correct, press ENTER to save.
8. Press the EMERGENCY STOP to exit Engineering Mode.
6.1 USING ENGINEERING MODE
CUSTOM SETTING DEFAULT MINIMUM MAXIMUM UNIT DESCRIPTION
Disable Errors OFF ON OFF N/A ON - Shows A-C class error codes. OFF - Shows only C class error
codes.
Elevation Minimum 28 20 239 N/A Controls the low incline parameter.
Elevation Maximum 230 20 239 N/A Controls the high incline parameter.
Auto Calibration N/A N/A N/A N/A This function is to calibrate the treadmill incline.
Speed Units MILE MILE KILOMETER DISTANCE Measurement unit used for calorie calculations, distance, and speed.
Pause Time 5 MINUTES 30 SECONDS 10 MINUTES SECONDS
/ MINUTES
Controls the maximum time the treadmill can be paused during a workout.
Serial Number N/A N/A N/A N/A Serial Number input is available for both the Console and Frame. Use the
number keys and UP / DOWN LEVEL keys to enter Engineering Mode.
Due to the limited LED characters, 2 layers are used to enter the serial
number. First Layer:
- PPPPP V
- PPPPP is the product name.
- V is the version. If the version is A, just leave this blank.
Second Layer
- YY MM nnnnn.
- YY is the year (11, 12).
- MM is the month (e.g. 08, 09, 10).
- nnnnn is the actual serial number.
Use the UP / DOWN LEVEL keys to navigate the layers and the number
keys to input the serial number. The product name is dependent on the
Machine Type setting.
For example, the console is TM519 with ver. A and the manufactured
date is 2012.09 with 18765. The frame is TM501 with ver. E and the
manufactured date is 2012.09 with 12345. Their serial numbers are:
Console SN: TM519 1st layer, 120918765 2nd layer.
Frame SN: TM501E 1st layer, 120912345 2nd layer.
Reset Default N/A N/A N/A N/A Reset default data to original.
Club ID 63 N/A N/A N/A This sets the club ID for clubs using Asset Management.
Audio Source OFF OFF / TV / PCTV /
REMOTE TV
N/A a. Off – no TV (keypad will not operate)
b. TV – All normal MYE TVs.
c. PCTV – All PCTVs (net based TV).
d. Remote TV – Wall mounted TVs with 900MHz receiver.
Volume Control OFF A. INPUT DEFAULT :15
B. MAX DEFAULT :32
C. OUTPUT DEFAULT :13
N/A Controls the default TV volume for entertainment wired through the
C-Safe port.
a. Input Default (DF : 15 / Range : 1 ~ 15)
b. Max Default (DF : 32 / Range : 1 ~ 32)
c. Output Default (DF : 13 / Range : 1 ~ Max)
Remote TV support a / b / c item. TV and PCTV only support c item.
AM System RF RADIO N/A To select AM output device by WIFI or RF Radio.
ERP Time (Sleep
time)
OFF OFF OR
0:01(MINUTES)~4:00(HOURS)
N/A If there is no use of the machine over a period of time, the console LEDs
will turn off (go into sleep mode).
6.2 ENGINEERING MODE OVERVIEW
