8
6.1 ENGINEERING MODE OVERVIEW
CHAPTER 6: ENGINEERING MODE
1) To enter Manager Mode, press and hold down the Quick Speed 2 and Quick Elevation 2 keys. Continue to hold down these two keys until
the display reads Manager Mode and hit PAUSE key to enter.
2) To scroll through the list of options in Manager Mode, use the quick key Speed UP and Speed DOWN LEVEL keys. Each of the custom set-
tings will show on the display.
3) To select a custom setting, press the PAUSE key when the desired setting is shown.
4) To change the value of the setting, use the quick key Speed UP and Speed DOWN LEVEL keys.
5) To confirm and save the value of the setting, press the PAUSE key.
6) To exit the setting without saving, press the STOP key.
7) Press and hold the STOP key for 3-5 seconds to return to normal operation.
Group Model Item1 Item2 Default Value Values/Range Unit Notes
Calibration T5GT Auto
Calibration
This option is to calibrate the elevation
parameters.
T5GT Elevation Min This option controls the minimum elevation
parameter.
T5GT Elevation Max This option controls the maximum
elevation parameter.
Running
Test
T5GT This option allows installers to do the belt
adjustment and test. Also this function will
not stop until press Stop or
exit the mode, it will provide customer for
demonstration and other functions.
Error Codes T5GT Disable/Enable Enable Disable/Enable This option displays the error code history
on the unit.
DAPI T5GT Server Production Dev/
QA/
Staging/
Production
Dev
unsecure domain: dev.dls.jfit.co port: 80
SSL domain: dev-dls.jfit.co port: 443
QA
unsecure domain: qa.dls.jfit.co port: 80
SSL domain: qa-dls.jfit.co port 443
Staging
unsecure domain: staging.dls.jfit.co port:
80
SSL domain: staging-dls.jfit.co port 443
Production
unsecure domain: dapi-ls.jfit.co port: 80
SSL domain: dapi-ls.jfit.co port: 443
T5GT SSL ON ON/OFF This option controls whether the internet
transmission with SSL (Secure Sockets
Layer) or not.
To Next Page
