Matrix T5X GROUP TRAINING User Manual

16
CHAPTER 8: TROUBLESHOOTING
8.2 ERROR CODES LIST
01XX: Motor Errors
CODE CLASS DESCRIPTION MACHINE SOLUTION
0140 B
Incline motor opera-
tion fail
T
Please run Auto Calibration.
- If the error code happens in Auto-calibration, the machine still can work and no
repairs are needed.
- If the error code happens in workout, please replace the incline motor.
0142
(01A2)
B
Incline motor is
detected in the
reverse of the
position indicated by
the potentiometer.
T
a. Check the connection of the incline motor cable at the MCB.
b. Run auto calibration.
c. If auto calibration fails, re-enter Engineering Mode and go to Calibration again.
- Select Calibration key.
- Check the MCB LEDs. If LED DOWN or UP has no light, check the console cable
connections at the console and MCB.
Replace the console or cable as needed. If LED DOWN or UP has a light, replace the
incline motor.
d. If the issue is not solved by replacing the incline motor, replace the MCB.
0144 B Motor over current T
a. Check the condition of the running deck and belt. Replace the belt and flip or
replace the running deck as needed.
b. Replace the MCB.
0147
(01A0)
B
Incline motor dis-
connection
T
a. Check the incline motor wire connection between the incline and LCB.
b. Check to see if incline value changes on display when up/down keys are pressed
(pins 1 & 2 for VR1 & VR2, pins 2 & 3 for VR2 & VR3).
- If there’s no change, replace the incline motor.
- If there’s a change, replace the LCB.
01A1 C
Incline calibration
error
T
a. It occurs when the calibration time is too long or the calibration distance is too
short.
b. Disconnect the incline tube from the frame. Turn on power and run auto calibration.
- If console still shows error, replace incline motor.
- If no error, reattach incline motor, and replace MCB.
01A3 C
Main motor discon-
nection
T
a. Check the connection of the motor cable at the MCB.
b. Using a multimeter, check the 3 points (U/V/W) and see if there’s a resistance
reading (pins 1 & 2 for U & V, pins 2 & 3 for V & W, pins 1 & 3 for U & W).
- If yes, replace MCB.
- If no, replace motor (a short or open circuiting).
01A8 C
Main motor over
current
T
a. Check the condition of the running deck and belt. Replace the belt and flip or
replace the running deck as needed.
b. Replace the MCB.
01AD
(0141)
B
Motor over tem-
perature
T
a. Check the connection of the motor cable at the MCB.
b. Use a multi-meter to check the motor wire circuit. Set the multi-meter to Ohms and
place both terminals on the blue wires of the motor cable.
- If there is an Ohm reading above 0, replace the motor.
- If the Ohm reading is 0, replace the MCB.
