CHAPTER 8: TROUBLESHOOTING
8.2 ERROR CODES LIST - CONTINUED
03XX: UCB Errors
CODE CLASS DESCRIPTION MACHINE SOLUTION
0301 A Memory block damage Console
a. Enter the Engineer mode disable B Level Error, bypass CLASS A and B error code.
b. Replace UCB.
0302 A UCB low battery voltage Console
a. Enter the Engineer mode disable B Level Error, bypass CLASS A and B error code.
b. Replace battery.
0303 A UCB low supply voltage Console
a. Enter the Engineer mode disable B Level Error, bypass CLASS A and B error code.
b. Make sure the RPM over 35, when the machine of self-power mode.
0304 A
Earphone Board needs
to be replaced
Console
a. Enter the Engineer mode disable B Level Error, bypass CLASS A and B error code.
b. Replace Earphone Board.
0305 A
USB Hardware OT or
OC
Console
a. Enter the Engineer mode disable B Level Error, bypass CLASS A and B error code.
b. Replace UCB.
0306 A
keypad is abnormal. The
keypad remains pressed
for 60 seconds
Console
a. Enter the Engineer mode disable B Level Error, bypass CLASS A and B error code.
b. Replace Keypad.
0340 B
keypad is abnormal. The
keypad remains pressed
for 5 seconds
Console
a. Enter the Engineer mode disable B Level Error, bypass CLASS A and B error code.
b. Replace Keypad.
0341 B Fan over current Console
a. Enter the Engineer mode disable B Level Error, bypass CLASS A and B error code.
b. Replace Fan.
0343 B UCB Over supply voltage Console
a. Enter the Engineer mode disable B Level Error, bypass CLASS A and B error code.
b. Check whether the LCB power input is over 13 voltage.
- If yes, replace MCB.
- If not, replace UCB.
0345 B
Correct packet but LCB
without the function
Console
a. Enter the Engineer mode disable B Level Error, bypass CLASS A and B error code.
b. Replace UCB
0346 B
UCB detect the error of
LCB incline position error
Console
a. Enter the Engineer mode disable B Level Error, bypass CLASS A and B error code.
b. Running the incline motor calibration again.
0347
(03A7)
B VA Load program fail Console
a. Enter the Engineer mode disable B Level Error, bypass CLASS A and B error code.
b. Replace VA Micro SD card
0348
(03A9)
B Motor does not to run Console
a. Enter the Engineer mode disable B Level Error, bypass CLASS A and B error code.
b. Replace UCB
03A5 C Failed to load program Console Replace UCB.
03A6 C Failed to run program Console Replace UCB.
03A8 C Machine type error All Choose the correct machine type in the console and reboot power again.
A NOTE ON CLASS A AND B ERROR CODES
Some errors can be bypassed in Engineering Mode in order to keep the machine in use.
˙ “Ignore B Level Errors” will bypass class A and B error codes.
˙ “Ignore Incline Errors” will bypass all incline errors.
