Inspecting the Matrox Orion HD package
You should check the contents of your Matrox Orion HD package when you first
open it. If something is missing or damaged, contact your Matrox representative.
Standard items
You should receive the following items:
•The Matrox Orion HD board.
• KX20 to 4 DVI-I cable adapter (two DVI-I connectors for input and two DVI-I
connectors for output).
SDI video output connector 2
SDI video output connector 1
SDI video input connector 1
SDI video input connector 2
Multi-format
input/output
connector
DVI-I connector 4/8
DVI-I connector 3/7
DVI-I connector 2/6
DVI-I connector 1/5
KX20
connector
4/8
3/7
2/6
1/5
