Board summary 45
Technical features of Matrox Orion HD
• Allows you to acquire data from two independent video sources at a time.
• Allows you to switch between video sources when multiple video sources are
connected.
• Supports the following analog video inputs:
- Standard definition (NTSC/PAL) video input in RGB, CVBS, Y/C, and YPbPr
(non-square pixels).
- High definition video input (720p, 1080i, and 1080p) at up to
60 frames/second in RGB.
- Video input from display boards (graphics adapters) in standard resolutions (up
to 1920 x 1200 at 60 frames/second
*
) in RGB.
• Supports the following digital video inputs:
- Standard definition (NTSC/PAL) (non-square pixels) SDI video input.
- High definition (720p, 1080i, 1080p) DVI-D and SDI video input at up to
60 frames/second.
- DVI-D video input from display boards (graphics adapters) in standard
resolutions (up to 1920 x 1200 at 60 frames/second
*
).
• When grabbing standard definition (SD), the multi-format video decoder
converts the video input into RGB888, YUV16, or YCbCr601; when grabbing
high-definition (HD) video, it converts the video input to RGB888, YUV16, or
YCbCr709. When grabbing video in SDI format, the data does not get converted;
standard definition (SD) video input is received in YCbCr601, and
high-definition (HD) video input is received in YCbCr709.
*. Higher frame rates are supported at lower resolutions.
