50 Appendix B: Technical information
Connectors on Matrox Orion HD boards
The Matrox Orion HD board has five interface connectors on its bracket. There
are two SDI video output connectors, two SDI video input connectors, and one
multi-format input/output connector.
The following image shows the Matrox Orion HD bracket and the Matrox
Orion HD board.
SDI video output connector 2
SDI video output connector 1
SDI video input connector 2
SDI video input connector 1
Multi-format
input/output
connector
