Chapter 3 Installation
- 26 -
Step Item Task
４
Installing drying
hopper base
Install the base to fitting position on molder as shown in Figure.
Fix it securely with 4 bolts.
HD-10,15 type base
HD-25～100 type base
HD-150～300 type base
picture 27
After installing it, remove adhes※ ive tape fixing slide gate.
