Chapter 4 Preparation for Operation
- 39 -
Step Item
3 After inspection and cleaning of inside, fix the removed parts again and close
cleaning door and set adjusting fastener or handle securely.
Lid
Catchclip
In case of
HD-75～200
HD-150～300 Diffuser fitting part
HD-75,100 Diffuser fitting part
Set pin
Diffuser
※
Fix it securely with set pin.
Diffuser
Hot air pipe
※
Fix it perpendicular to hot air
pipe.
catchclip.
Picture 45
To Next Page
