Chapter 4 Preparation for Operation
- 38 -
Step Item
2-2
（In case of HD-150，200）
※Remove diffuser by moving it up and down or rotating it
along groove of hot air pipe.
Hot air pipe
Diffuser
Inner and outer surface
cleaning
Lid
Inner sruface
cleaning
Picture 43
（In case of HD-250，300）
Inner surface
cleaning
Hot air pipe
handle
Diffuser
Inner and outer
surface cleaning
Take the handle of diffuser and remove
diffuser by moving it up and down or
rotaining it along the groove of hot air
pipe.
Picture 44
