Appendix
- 76 -
Electric parts table
Type：DMS2-80,120,170,240 A Marker：50Hz/60Hz (High temperature) φ3
NO. Code Name Specifications Number Remark
NF63-CW 3P 10A(16A) (80)
NF63-CW 3P 16A(20A) (120)
NF63-CW 3P 20A(32A) (170)
NF63-CW 3P 32A(40A) (240)
MITSUBISHI
380V/415V
NF63-CW 3P 20A(32A) (80)
NF63-CW 3P 32A(40A) (120)
NF63-CW 3P 40A(50A) (170)
1 NFB-1 Breaker
NF63-CW 3P 50A(63A) (240)
1
MITSUBISHI
200V/220V
2 Terminal cap TCS-05SW3W 1 MITSUBISHI
3 V hander V05SWEF 1 Red/Yellow for anon stop
SC-03 AC200V 1 FUJI(380V/415V)
SC-03 AC200V (80～170)
4 MS-1 Contactor
SC-4-1 AC200V (240)
1
FUJI
200V/220V
SC-4-1 AC200V
1 FUJI(380V/415V)
SC-4-1 AC200V (80,120)
SC-N1 AC200V (170)
5 MC-0 Contactor
SC-N2 AC200V (240)
1
FUJI
200V/220V
6 SSR-1 Solid relay TSR-25DA-H+TSR-100 1 YangMing
7 SSR-2 Solid relay
TSR-25DA-H+TSR-100
(Only 170 high temp,240 have)
1 YangMing
8 SSR-3 Solid relay TSR-25DA-H+TSR-100 1 YangMing
