Appendix
- 77 -
Type：DMS2-80,120,170,240 A Marker：50Hz/60Hz (High temperature) φ3
NO. Code Name Specifications
Numbe
r
Remark
TR-ON/3(2.2-3.4A)(80，120)
TR-ON/3 (4-6A) (170)
TR-ON/3 (5-8A) (240)
1
FUJI
380V/415V
TR-ON/3 (4-6A) (80,120)
TR-ON/3 (6-9A) (170)
1 OCR-1 Thermal relay
TR-5-1N/3 (9-13A) (240)
1
FUJI
200V/220V
2 SK1 Auxiliary contact SZ-A20 1 FUJI
SZ-A40 1
FUJI
(380V/415V)
SZ-A40 (80,120)
3 SK2 Auxiliary contact
SZ-A20 (170,240)
1
FUJI
200V/220V
4 F-1 Fuse TFB101N 3A 1 Taiwan Tiande
5 CR-1 Relay
MY4J AC220V/PYF-14A
1 OMRON
6 TH-1 Over-temperature relay
TS-200S 1 SuZhou Zhihe
7 TH-2 Over-temperature relay
A255℃
1 NGT(Japan)
8 Tr-1 Transformer
JBK3-300 AC380,400,415
/200V
JBK3-300 AC220/200V
1
WuXi
(Only 220～415V
have)
9 K Thermocouple
T-35K Type φ3.2×70（+15）×1.5A
2 Shanghai Hongduan
10 TC-1 Temperature control G2422 1 set TOHO Electronic
Metal connective
terminal
BVH-21T-P1.1 (JST) 12 TOHO Electronic
11
Metal connective
terminal
BXH-001T-P0.6 (JST) 18 TOHO Electronic
12 FAN Cooling blower SJ9225HA2B AC200V 1 Shanghai KAKU
13 DC-1 DC power RS-25-24 1 Taiwan Mingwei
14 PB-1 Button AR22FOR-10W 1 FUJI White
15 TB-1 Line blank NHT-1023 1
WEIZHE corporation
16 TB-2 Line blank NHT-3003+1006 1
WEIZHE corporation
17 BZ Buzzer EA4202 AC200V 1 Panasonic
18
φ22.5 Brand
CONTROL ON 1 CMC
