SPECIFICATIONS
Model name MAX Electronic Stapler EH-70F
Capacity 2 – 70 sheets (64gsm, 55kg / 16-lb.bond paper)
Stapling speed 2 staples per second
Stapling system Motor driven link mechanism with automatic feed
Throat depth Auto stapling: Adjustable approx. 6 to 18 mm (1/4” to 3/4”)
Manual stapling: Adjustable approx. 3 to 18 mm (1/8” to 3/4”)
Dimensions 100mm (4”) (W) x 112mm (4-1/2”) (H) x 210mm (8-1/4”) (L)
Weight 1.2Kg (2.7 lbs)
Power consumption Approx. 13W
Power source DC24V, 2.08A
Use only specified AC adapter (AC100-240V, 50-60 Hz) appended
to machine.
Working Temp. and 5 /41 – 35 /95 , Below 80% RH (non-condensation)
Humidity ranges
Staple cartridge MAX No.70FE staple cartridge
Contains a guaranteed minimum of 5,000 staples.
1. Stapling capacity depends on the kind of paper. The machine might not staple up to 70
sheets in the other kind of paper. In this case, do not staple it forcibly.
2. In case of stapling continually for a long time, the machine might not staple because the
motor would be very hot. In this case, stop operating for 30 minutes or more to cool motor.
And then, start to operate again.
3. Operate less than 70 sheets (55kg / 16-lb.bond paper). It could cause damage the
machine when operating the machine over the specification.
4. Contact your dealer or distributor with telephone or e-mail if machine would be out of order
or you have any problem.
15
