Configuration Jumpers
Figure 4 shows the location of the configuration jumpers.
Figure 4. Configuration Jumpers
SSI Front Panel Connector
The server board provides a 24‑pin SSI front panel connector. The following figure shows the pin‑out
for this connector.
Figure 5. SSI Front Panel Connector
A. Power LED D. Reset Button
B. HDD LED E. NIC1 LED
C. Power Button F. NIC2 LED
3
2
J1F5
3
2
J1F2
3
2
J1F3
3
2
J1F1
3
2
J1A2
A
B
C
D
E
F
BMC
Force
Update
Default
CMOS
Clear
Password
Clear
BIOS
Recovery
ME
Force
Update
Enabled
Default
Enabled
Default
Recover
Default
Password
Clear
Default
CLEAR
CMOS
