MAXDATA PLATINUM 100 I - Closing Load Plate and Socket Lever

14 15MAXDATA PLATINUM 100 I M9Hardware Installations and Upgrades
14 15MAXDATA PLATINUM 100 I M9Hardware Installations and Upgrades
12. Close the load plate (see letter “A”), close the socket lever, and ensure the load plate tab
engages under the socket lever when fully closed (see letter “B” and “C”).
Figure 10. Closing Load Plate and Socket Lever
13. Attach the heat sink (see next page).
AF003191
Grosse Point Server Board
AF003191.ai
11 May 2009
Heideman Assoc.
A
B
D
C
