PB 9MAXDATA PLATINUM 100 I M9Server Features
2 Server Features
This chapter briefly describes the main features of the server system. This chapter provides a list of
server system features and diagrams showing the location of important components and connections
of the server system.
Table 2 summarizes the features of the server system.
Table 2. Feature Summary
Feature Description
Chassis Dimensions 450 mm high
195 mm wide
501 mm deep
18.0 kg max. chassis weight
Processor • Support for one Intel
®
Xeon
®
3400 Series Processor
• LGA 1156 socket
Memory Two memory channels with support for 1066/1333 MHz ECC Unbuff-
ered DDR3 DRAM (UDIMM) or ECC Registered DDR3 DRAM (RDIMM,
Intel
®
Xeon
®
3400 Series only).
• Up to 2 UDIMMs or 3 RDIMMs (Intel
®
Xeon
®
3400 Series only) per
channel
• 32 GB max with x8 ECC RDIMM (2 Gbit DRAM) and 16 GB max with
x8 ECC UDIMM (1 Gbit DRAM)
Chipset • Intel
®
3420 Chipset Platform Controller Hub (PCH)
• ServerEngines LLC Pilot II BMC controller (Integrated BMC)
Peripheral Interfaces External connections:
• One DB-15 graphics port
• One DB-9 serial port A
• Two RJ45 network ports for 10/100/1000 Mbps
• Four USB 2.0 ports (back panel)
• Two USB 2.0 ports (front)
Internal connections:
• One 2x5 USB connector for two USB 2.0 ports
• One vertical type A USB connector
• One 2x5 connector for serial port B
• Six SATA-II ports with integrated RAID support
(Matrix Storage Raid Technology, Raid 0, 1, 5, 10)
• One port for a remote management module 3 (optional)
Video
On-board controller ServerEngines LLC Pilot II with integrated 2D video
controller, 64 MB DDR2 memory, 8 MB of which is graphics memory
LAN • One Gigabit Ethernet 82574L controller
• One Gigabit Ethernet 82578DM controller
Expansion Capabilities • Slot 1: 5V PCI 32 bit / 33 MHz
• Slot 2: PCI Express Gen1 x4 (x1 connection, optional)
• Slot 3: PCI Express Gen1 x8 (x4 connection)
• Slot 4: PCI Express Gen2 x8 (x4 connection, optional)
• Slot 5: PCI Express Gen2 x8 (x8 connection)
• Slot 6: PCI Express Gen2 x16 (x8 connection)
Hard Drives • up to four SATA-II hard drives
• up to two internal SATA hard drives
• support for optional 3x hot-swap drive cage (occupies two
5,25” bays)
• support for optional internal 4x drive cage
Power supply Efficient 300 W power supply (80 PLUS
®
)
Fans Support for two system fans and one processor fan
System Management Integrated IPMI 2.0-compliant baseboard management controller
•
Support for remote management module 3 (“KVM over IP”, optional)
• Support for system management software
