Specifications
W:210 × D:140 × H:45
490g receiver
950 MHz~2150 MHz
55 MHz/8 MHz (unders 5MS/s)
13/18 V GS, 0,30 A max. Overload protection
22 KHz ± 2 KHz, 0,6 V pp ± 0,2 V
Version 1.0, Version 1.2
1~45 MS/s
Max. 15 Mbit/s
1/2, 2/3, 3/4, 5/6, 7/8, auto
4:3 Letterbox, 4:3 PanScan, 16:9 Auto
720 x 576 (Pal), 720 x 480 (NTSC),
1280 x 720, 1920 x 1080
Left, right, stereo Mono, AC3 digital sound
3A blade fuse – standard automotive type
Type F, IEC 169-24
Video CVBS, RGB, Audio L, R
Video CVBS, RGB, Audio L, R
Audio L,R
Connection for digital/HD transmissions
Component output
USB 2.0 interface
100-240V ~, 50/60 Hz
12V, 1.5 A
12V
ca. 12W (operating with single LNB) ca.1 W (standby)
0ºC – +40ºC
- 40ºC – +65ºC
Receiver
Dimensions in mm
Weight in grammes
Range of input frequency
IF band width
LNB power supply
LNB control
DiSEqC control
Symbol rate
Input speed
Error correction (FEC)
Aspect ratio
Video resolution
Audio mode
Fuse type
Connection options
LNB IF input
TV SCART (output only)
VCR SCART (output and input)
RCA (CINCH)
HDMI interface
YPbPr
USB
Current supply
Input voltage power pack
Output voltage power pack
Receiver input voltage
Receiver consumption
Operating temperature
Storing temperature
