Step 12: Assembling the Bottle Holder

Loosen and remove two screws M5 (B05) which are preassembled on the handlebar stem (A02).

Attach the bottle holder (C27) to the handlebar stem using the two screws (B05) that were just loosened.

Assembly

A02

C27

B05

Step 13: Assembling the Pedal Covers

Now press four covers (C14) into the round holes on the top of each pedal.

C14
