2202G1JE-DA-M-N_2010.01.
2 Configuration and Specification of Compressor
Reciprocating Compressor M Series 2.1 Configuration of Compressor
2-2
Fig. 2-2 Overall view (Ex: 62M-FM)
No. Description No. Description
1
Compressor
8
Base (Optional)
2
Suction shut-off valve (Optional)
9
Belt cover (Optional)
3
Discharge shut-off valve (Optional)
10
Motor (Optional)
4
Safety valve (Optional)
11
Motor pulley (Optional)
5
Flywheel (Optional)
12
V-belt (Optional)
6
Oil cooler (Optional)
13
Control switch (Control console) (Optional)
7
Oil heater (Optional)
14
Unloader solenoid valve
For names of each part, refer to "7.1 Development View and Configuration Table of the Parts".
To Next Page
