MAYEKAWA 8M - Attentions for Attaching the Oil Cooler Piping;Water Cooled Type Oil Cooler

2202G1JE-DA-M-N_2010.01.
5 Maintenance
Reciprocating Compressor M Series 5.5 Disassembly/Assembly
5-12
5.5.1.10 Attentions for Attaching the Oil Cooler Piping/Water Cooled Type Oil
Cooler
1. Attach the water cooled type oil cooler, and
temporarily tighten the tightening nuts (b) of the
cooler.
2. Attach the oil cooler piping.
3. Fully tighten the tightening nuts (b) of the water
cooled type oil cooler.
