5 Maintenance
Reciprocating Compressor M Series 5.5 Disassembly/Assembly
5-16
Quantity
Symbol Description Size
4M 6M 8M
A
Hexagon head bolt (No.1),
discharge manifold
M16×L200
0 3 0
B
Hexagon head bolt (No.2),
discharge manifold
M16×L170
8 10 20
C
Hexagon head bolt (No.3),
discharge manifold
M16×L120
4 4 4
D
Hexagon socket head cap screw
(No.4), discharge manifold
M16×L55 (hexagon socket set
screw)
0 1 0
