Maytag CWG3100AA Series User Manual

©2005 Maytag Services 16026549 17
To avoid risk of electrical shock, personal injury or
death; disconnect power and gas before servicing,
unless testing requires power and/or gas.
Disassembly Procedures
Removing Oven Door
WARNI NG !
To avoid risk of personal injury or property damage,
do not lift oven door by the handle.
1. Turn off gas and remove power from unit (at the
circuit breaker).
2. Open oven door approximately 4 inches (door "stop"
position).
3. Grasp door on both sides and lift door up evenly until
door clears the hinge arms.
WARNI NG !
To avoid risk of personal injury or property damage,
do not place fingers between hinge arms and oven
frame. Hinge arms are spring-loaded and will slam
shut against the unit if accidently closed, which may
cause injury or damage to the unit.
4. Place door in safe location.
5. Reverse procedures to reassemble.
Replacing Oven Door Hinge
WARNI NG !
To avoid risk of personal injury or property damage,
do not lift oven door by the handle.
1. Remove oven door, see "Removing Oven Door"
procedure.
2. Remove screws securing oven door hinge to oven
chassis.
3. Gently pull the oven door hinge forward through the
hinge opening located in the front of the frame.
4. Reverse procedures to reassemble.
Upper Oven Door Disassembly
1. Remove oven door, see "Removing Oven Door"
procedure.
2. Remove screws securing door lining to door panel.
3. Remove screws securing door glass clips to door
panel, allowing for the removal of the door glass
panel, if necessary.
4. Remove screws securing door lining to door baffle.
5. Remove screws securing door baffle to window
frame.
6. Remove screws securing window to window frame.
Place window in save location.
7. Remove screws securing door handle to door panel.
8. Reverse procedures to reassemble.
Lower Oven Door Disassembly
1. For Models CWG3600AA*, see "Upper Oven Door
Disassembly" procedure.
2. For Models CWG3100AA*, remove lower oven door,
see "Removing Oven Door" procedure.
3. Remove screws securing door lining to door panel.
4. Remove screws securing door glass clips to door
panel, allowing for the removal of the door glass
panel, if necessary.
5. Remove screws securing window to window frame.
Place window in save location.
6. Remove screws securing door handle to door panel.
7. Reverse procedures to reassemble.
