‘off’ to ‘on’ or from ‘on’ to ‘off’. If the selected
function is currently active (commanded
‘on’), the seven segment display will flash
the function number at a 1 Hz rate (1 flash per
second). If the function is currently commanded
‘off’, the seven segment display will show
the function number without flashing. NOTE:
Activating any of the spin or agitate functions
will result in functions 10–14 reporting their
status as ‘on’ because reported status is based
on motor motion being commanded.
Failure to Turn Function On Indication
If the number of functions (pumps, valves,
and motor) allowed on at the same time or
the conditions to actuate the function are not
correct, the display will turn off momentarily
and a tone will sound.
The chart below indicates function and test
cycle function numbers:
Chart 1 – Load and Test Cycle Function Number
NOTE: Some functions will not be available on all models
Display Function Notes
000 Toggle Lid Lock Note: To lock or unlock the lid, all functions (pumps, motor,
valves, and heater) must be off and the lid must be closed.
001 Toggle Cold Valve
002 Toggle Hot Valve
003 Toggle Fresh Fill Valve N/A
004 Toggle Detergent Valve N/A
005 Toggle Fabric For water to flow, cold water should be turned on first.
Softener Valve Note: If the fabric softener valve is turned “ON” without the
cold water valve “ON”, water can overflow the front of the tray.
006 Toggle Oxi Valve For water to flow, hot water should be turned on first.
Note: If the Oxi valve is turned “ON” without the hot water valve
“ON”, water can overflow the front of the tray.
Note: Oxi not available on all models.
007 Toggle Bleach Valve Note: On models with dump bleach dispenser, toggling this load
will turn on the Oxi valve.
008 Toggle Drain Pump
009 Toggle Recirc. Pump Note: Not available on all models.
010 Toggle Low Lid must be closed and locked for this to be enabled.
Speed Spin Note: The basket must be empty for this function.
011 Toggle Mid Lid must be closed and locked for this to be enabled.
Speed Spin Note: The basket must be empty for this function.
012 Toggle High Lid must be closed and locked for this to be enabled.
Speed Spin Note: The basket must be empty for this function.
013 Toggle Slow Agitate Lid must be closed and locked for this to be enabled.
Note: The basket must be empty for this function.
014 Toggle Fast Agitate Lid must be closed and locked for this to be enabled.
Note: The basket must be empty for this function.
015 Toggle Shifter Switch in and out of Spin. Shifter On = Spin and Shifter Off =
Agitate. Note: This can only be commanded while the motor is
not running. The shifter will also be on when spin functions
10–12 are active.
016 Toggle Basket Light N/A
017 Toggle Heater Note: To actuate the heater, all functions (pumps, motor, and valves)
must be off and water level must be above the impeller.
050 Run Factory Calibration Note: For factory test only.
051 Service Diagnostics Service Diagnostics for repair verification and installation
Verification Cycle verification. The Soil Level and Temperature buttons can be
used to review step results if Pass/Fail criteria exist. If a step
has no Pass/Fail criteria, --- will be displayed.
052 Run Load Size This calibrates the main control to the washer for optimal load size
Calibration Cycle sensing. Upon completion, the UI will display 000.
053 Run Dry Factory Note: For factory test only.
Calibration Cycle
075 Set Life Test Mode Note: For factory test only. If life test mode is accidentally
activated, Life Test can be exited by removing power from the
washer and waiting for the control to power down as indicated
by the diagnostic LED ceasing to flash (see Figure 1, page 2).
