Fault Code Overview
CODE MESSAGE FAILURE FAULT OCCURRENCE ACTION
E2
No Drain End Drain failure Draining Full Stop + Tumble
E3
Tilt Fault Safety switch activated Whole cycle, revolutions
under distribution revolutions
level
Full Stop + Tumble
E4
Imbalance Safety switch activated
during transition from
distribution into spin
sequence
Spin Skip + Continue
E5
Tilt High Sp Safety switch activated at
high revolutions
High revolutions Full Stop + Safety Time
E6
Door Switch Door switch failure Whole cycle Full Stop + Safety Time
E7
Door Coil Door lock failure Whole cycle Full Stop + Safety Time
E8
Door Start Door lock failure in beginning
of cycle
Beginning of cycle Do not start
E9
Door End Door lock opening failure at
end of cycle
End of cycle Do not start
E11
No Fill Fill failure Filling Full Stop + Request for Continue
E12
OverFill Failure due to water overfill
(water level above pre-set
value)
After or during filling Full Stop + Tumble
E13
No Heating Heating failure Heating Full Stop + Tumble
E14
Heat. Time Heating time failure Heating Full Stop + Request for Continue
E15
Too Hot Too hot Heating Full Stop + Tumble
E21
OverFlow Water level too high After or during filling Full Stop + Tumble
E24
Level Sens. Defective level sensor Before start up Continue + Do not start
E25
Temp Sensor Defective temperature sensor Before start up Continue + Do not start
E26
Mitsub. Code Undefined frequency inverter
error code
Whole cycle Full Stop + Tumble
E27
Invert.Com. Communication fault inverter Whole cycle Full Stop + Safety Time
E28
THT time THT Time out Spin sequence Full Stop + Safety Time
E29
OV3/OP time OV3 Time out/E.OP Spin sequence Full Stop + Safety Time
E31
Load Par Initialization fault frequency
inverter
Parameter set-up Do not start
E32
Verify Par Verification fault frequency
inverter parameters
Parameter loading Do not start
E35
Wrong Softw Incorrect software version Using new software version Do not start
E36
Imbalance Unbalance detection system
activated
Spin sequence Reduction of spinning sequence
revolutions (for information only)
E37
No Drain Spr Drain failure at spray
sequence
Spray sequence Full Stop + Tumble
E39
Out of Soap Soap supplies running out of
soap
Wash step For information only
E41
Service Due Service due warning End of cycle For information only
Open door = reset
E42
Connection No network connection Data transfer networking For information only
E43
Voltage Par Incorrect voltage range
selection
Configuration menu Make correct selection
E44
Model Type Incorrect selection of
machine type
Configuration menu Make correct selection
