Tyre chain selection (Europe)
Mazda recommends hexagon type
steel ring chains. Select the proper
type according to your tyre size.
Tyre size Tyre chain
205/60R16 Hexagon type
215/45R18 Hexagon type
NOTE
Although Mazda recommends
hexagon type steel ring chains, all
chains within the installation
specifications
may be used.
Installation
specification
(Europe)
When installing tyre chains, the
distance between the tyre tread and
the chain must be within the
prescribed limits in the following table.
Distance [Unit: mm (in)]
AB
MAX 9 (0.35) MAX 9 (0.35)
Side view
1. A
Cross section view
1. B
Installing the chains
1. If your vehicle is equipped with
wheel covers remove them,
otherwise the chain bands will
scratch them.
2. Secure the chains on the front tyres
as tightly as possible. Always follow
the chain manufacturer's
instructions.
3. Retighten the chains after driving
1/2―1 km (1/4―1/2 mile).
Before Driving
Driving Tips
3-58
