Instrument Cluster and
Display
▼
Instrument Cluster and Display
① Instrument Cluster.......... page 4-23
② Active Driving Display..... page 4-42
Instrument Cluster
▼
Instrument Cluster
① Tachometer.................... page 4-24
② Multi-information Display...............
..................................... page 4-25
③ Engine Coolant Temperature
Gauge............................page 4-28
④ Fuel Gauge..................... page 4-28
⑤ Instrument Panel Illumination
Switch............................page 4-29
⑥ Speedometer..................page 4-23
⑦ TRIP Switch.................... page 4-27
▼
Speedometer
The speedometer indicates the speed
of the vehicle.
When Driving
Instrument Cluster and Display
4-23
