Mazda 3 2020 - Page 353


A large deviation in the installation
position of a rear side radar sensor
on the vehicle has occurred.

There is a large accumulation of
snow or ice on the rear bumper
near a rear side radar sensor.

Driving on snow-covered roads for
long periods.

The temperature near the radar
sensors becomes extremely hot
due to driving for long periods on
slopes during the summer.

The battery voltage has decreased.

Under the following conditions, the
rear side radar sensor cannot detect
target objects or it may be dicult to
detect them.

The rear side radar sensor
detection area is obstructed by a
nearby wall or parked vehicle.
(Reverse the vehicle to a position
where the radar sensor detection
area is no longer obstructed.)
1. Your vehicle

A vehicle is approaching directly
from the rear of your vehicle.
1. Your vehicle

The vehicle is parked on a slant.
1. Your vehicle

A vehicle is approaching from the
opposite direction on a steep
gradient.
1. Your vehicle

Directly after the SBSRC system
becomes operable using the
personalisation feature.

Radio wave interference from a
radar sensor equipped on a nearby
parked vehicle.

Turn
o
the
SBSRC
system while
pulling a trailer or while an accessory
such as a bicycle carrier is installed to
the rear of the vehicle. Otherwise,
the radio waves emitted by the radar
will be blocked causing the system to
not operate normally.

In the following cases, a rear radar
and rear camera may detect
something as a target obstruction
which could cause the
SBSRC
system to operate.

Hanging curtains, gate poles such
as at toll gates and railroad
crossing.

When travelling near objects such
as foliage, barriers, vehicles, walls,
and fences along a road.
When Driving
i-ACTIVSENSE
4-195
