Distance De-
tection area
Distance between vehicle and obstruction
Beeper sound
*1
Front ultrasonic sensor Rear ultrasonic sensor
Close distance
Within approx. 35.0 cm (13.7
in)
Within approx. 35.0 cm (13.7
in)
Continuous
sound
*
1 The rate at which the intermittent sound beeps increases as the vehicle approaches the obstruction.
Front corner ultrasonic sensor
*
, Rear corner/Rear side
*
ultrasonic sensor
Distance Detection
area
Distance between vehicle and obstruction
Beeper sound
*1
Front corner ultrasonic sensor/Rear corner,
Rear side ultrasonic sensor
Far distance
Approx. 55.0―38.0 cm (21.6―14.9 in)
Medium intermittent
sound
Middle distance
Approx. 38.0―25 cm (14.9―9.8 in)
Fast intermittent sound
When Driving
Parking Sensor System
*Some models.
4-275
