No.
FUSE RAT
ING
PROTECTED COMPONENT
F2 20 A
Windscreen wiper de-icer
*
F3
30 A
Engine control system
*
20 A
Injector
*
F4 20 A
SVT
*
F5 40 A Engine control system
F6 20 A
SVT
*
F7
15 A
Fuel warmer
*
20 A
Fuel pump
*
F8 15 A Engine control system
F9 15 A
Transmission control system
*
F10 15 A Engine control system
F11 7.5 A Air conditioner
F12 15 A Engine control system
F13 15 A
NOx sensor
*
F14 20 A
Front seat warmer
*
F15 20 A
Headlight washer
*
F16 15 A For protection of various circuits
F17 ――
F18 15 A Accessory sockets
F19 60 A Power steering system
F20 15 A Headlight (LH) 1
F21 15 A Headlight (RH) 1
F22 15 A Keyless system
F23 30 A ABS, Dynamic stability control system
F24 15 A Headlight (LH) 2
F25 15 A Headlight (RH) 2
F26 7.5 A On board diagnostics
F27 25 A For protection of various circuits
F28 25 A For protection of various circuits
F29 15 A Windscreen washer
F30 ――
F31 15 A Horn
Maintenance and Care
Owner Maintenance
*Some models.
