Mazda 3 2020 - Page 571

Hatchback
1. Remove the luggage mat.
2. Remove the jack.
To secure the jack
Saloon
1. Insert the wing bolt into the jack
with the jack screw pointing to the
front and turn the wing bolt
clockwise to temporarily tighten it.
2. Turn the jack screw clockwise.
1. Wing bolt
2. jack screw
3. Turn the wing bolt completely to
secure the jack.
NOTE
If the jack is not completely secured, it
could rattle while driving. Make sure
the jack screw is suciently tightened.
Hatchback
Perform the removal procedure in
reverse.
Maintenance

Always keep the jack clean.

Make sure the moving parts are kept
free from dirt or rust.

Make sure the screw thread is
adequately lubricated.
If Trouble Arises
Flat Tyre
7-27
