Security Indicator Light
If the security indicator light flashes
continuously while you are driving, do
not shut
o
the engine. Go to an
expert repairer (we recommend an
Authorised Mazda Repairer) and have
it checked. If the engine is shut o
while the indicator light is
flashing,
you
will not be able to restart it.
Make sure the key is within the
operational range for signal
transmission. Switch the ignition o,
and then restart the engine. If the
engine does not start after 3 or more
tries, contact an expert repairer (we
recommend an Authorised Mazda
Repairer).
NOTE
Because the electronic codes are reset
when the immobilizer system is
repaired, the keys are needed. Make
sure to bring all the keys to an
Authorised Mazda Repairer so that
they can be programmed.
▼
AWD Warning Indication/
Warning Light
“AWD Malfunction. Front Wheel
Drive Only. Have the Vehicle
Inspected” is displayed/When the
light is turned on
The indication is displayed/the light
turns on under the following
conditions. The system may have a
malfunction. Have the vehicle checked
at an expert repairer (we recommend
an Authorised Mazda Repairer).

When there is a malfunction in the
AWD system.
“Excessive AWD System Load. Drive
Slowly Until Warning Light Turns O.
Vehicle Now in Front Wheel Drive” is
displayed/When the light is flashing
The indication is displayed/the light
flashes
under the following conditions.
Park the vehicle in a safe place and
check that the warning indication light
turns
o/
the warning light stops
flashing, and then drive the vehicle.
Contact an expert repairer (we
recommend an Authorised Mazda
Repairer) if the indication is
continuously displayed.

When the dierential oil temperature
is excessively high.

When there is a large dierence
between the front and rear wheel
rotation, such as when trying to
remove the vehicle from mud.
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
