(See No.3 Engine Mount and No.4 Engine Mount Rubber Removal Note.)
(See No.3 Engine Mount and No.4 Engine Mount Rubber Installation Note.)
6
Engine, transaxle
Main Fuse Block Connector Removal Note
1. Release the tab in the order shown in the figure.
2. Pull the lock lever up and remove the connector.
No.3 Engine Mount and No.4 Engine Mount Rubber Removal Note
1. Secure the engine and the transaxle using an engine jack and attachment as shown in the figure.
No.3 Engine Mount and No.4 Engine Mount Rubber Installation Note
1. Secure the engine and the transaxle using an engine jack and attachment as shown in the figure.
2. Install the No.1 engine mount rubber and No.4 engine mount rubber.
