856
3. Remove in the order indicated in the table.
1
Purge solenoid valve
4. Install in the reverse order of removal.
PURGE SOLENOID VALVE INSPECTION
B3E011618740W03
Evaporative Purge Control Inspection
Without using WDS or equivalent
1. Warm up the engine and idle it.
2. Disconnect the vacuum hose which is connected to the charcoal canister from purge solenoid valve.
3. Place your finger onto the purge solenoid valve as shown in the figure and verify that vacuum is
applied.
LF
Z6
