Jack
*
To re m ove the jac k
1. (With luggage board)
Lift up the luggage board.
2. (With luggage board)
Pull the luggage board outward a little
and insert the opposite end into the
holders so that the luggage board
stands.
Luggage board
Holders
3. Lift the luggage mat.
Luggage mat
4. Remove the cargo sub compartment.
5. Remove the cover.
Tabs
6. Turn the wing bolt and jack screw
anticlockwise.
Wing bolt
Jack screw
If Trouble Arises
Flat Tyre
*Some models.
7-5
