Signal Warning/Indicator Lights Page
Door-Ajar Warning Indication 4-35
Liftgate-Ajar Warning Indication 4-36
Low Washer Fluid Level Warning Indication 4-36
Tire Pressure Monitoring System Warning Light 4-36
KEY Warning Indication 4-38
Wrench Indication 4-40
TCS/DSC Indicator Light 4-40
TCS OFF Indicator Light 4-40
AFS OFF Indicator Light 4-40
Smart City Brake Support (SCBS) OFF Indicator Light 4-41
Low Engine Coolant Temperature Indicator Light (Blue) 4-41
Shift Position Indication 4-41
Headlight High-Beam Indicator Light 4-42
Turn Signal/Hazard Warning Indicator Lights 4-42
