Signal Warning/Indicator Lights Page
Security Indicator Light 4-42
Cruise Main Indicator Light (Amber)/Cruise Set Indicator Light (Green) 4-42
Lights-On Indicator Light 4-43
qType B
Warning/Indicator lights will appear in any of the highlighted areas
Signal Warning/Indicator Lights Page
Master Warning Light 4-28
Brake System Warning Light 4-28
ABS Warning Light 4-29
Charging System Warning Light 4-30
Engine Oil Warning Light 4-30
Check Engine Light 4-31
High Engine Coolant Temperature Warning Light (Red) 4-31
4-26
When Driving
Instrument Cluster and Display
