59
REF. QTY. PART No. DESCRIPTION
FLAILHEAD ASSEMBLY
1 1 4000182 CYLINDER FIXING STIRRUP
2 2 4000184 STOP BRACKET
3 2 4000183 RUBBER STOP
4 1 4000185 RAM BRACKET
5 1 4000186 HYDRAULIC RAM
6 1 4000187 HEAD CASING (1.3m)
7 1 4000188 CLAMP STRIP
8 1 4000189 RUBBER FLAP
9 1 4000190 ROTOR (1.3m)
10 2 4000191 ROTOR BEARING SUPPORT
11 1 4000192 HEAD PIVOT BRACKET
12 1 4000193 PIVOT JOINT
13 1 4000194 ROLLER
14 1 4000195 ROLLER BRACKET - R/H
15 1 4000196 ROLLER BRACKET - L/H
16 1 4000197 LEFT SKID
17 2 4000198 WASHER
18 1 4000199 PLATE
19 1 4000200 RIGHT SKID
20 1 4000201 MOTOR MOUNTING PLATE
21 1 4000202 BELT COVER
22 1 4000203
FRONT HOOD
(Builds to S/N ROBO071300390)
1 4001257
FRONT HOOD
(Builds from S/N ROBO071300391)
23 1 4000204
SPRING BRACKET
(Fits Spring 4000219 only)
1 4000338
SPRING BRACKET
(Fits Springs 4000219 & 4000749)
24 1 4000205 SPRING TENSIONER FIXING
25 1 4000206 SPRING TENSIONER
26 1 4000255 Y-FLAILS KIT (SINGLE STATION)
1 4000268 Y-FLAILS KIT (22 STATION)
27 1 4000208 SCREW
28 1 4000252 SCREW
29 2 4000209 SCREW
30 1 4000210 SCREW
31 1 4000211 SCREW
32 2 4000212 SCREW
33 1 4000213 SCREW
34 1 4000214 SCREW
35 1 4000215 SCREW
36 1 4000216 SCREW
4001297 SEAL KIT FOR HYDRAULIC RAM 4000186
When replacing the now obsolete early type Spring 4000219 with the later type Spring 4000749
the early type Bracket 4000204 must also be replaced with later type bracket 4000338.
FLAILHEAD ASSEMBLY– Robocut S/No: ►ROBO021400399
ROBOCUT FLAILHEAD
