33
REF. QTY. PART No. DESCRIPTION
REVERSIBLE FAN ASSEMBLY
1 1 4001237 COMPRESSOR ASSEMBLY
- comprising of:
2 2 4001238 CYLINDRIC HEAD SCREW
3 2 4000789 WASHER
4 1 4000450 COMPRESSOR CLAMP
5 2 4000449 FLANGED NUT
6 1 4000446 COMPRESSOR
7 2 4000453 HOSE CLAMP
8 4 4001239 KNURLED WASHER
9 1 4000466 AIR HOSE
10 1 4001240 FAN FLANGE
11 4 4000543 CYLINDRIC HEAD SCREW
12 8 4000472 FLANGED HEAD SCREW
13 1 4001241 REVERSIBLE FAN
14 8 4001242 SCREW
15 12 4001243 SPRING KIT
16 4 4000699 BLADE SET FOR FAN (2 BLADES)
17 1 4001244 IRON PIPE KIT
18 1 4001245 AIR FILTER SUCTION LINE KIT
- comprising of:
19 1 4001246 SLEEVING
20 1 4001247 JUBILEE CLIP
21 1 4001248 CONNECTOR
22 1 4001249 HOSE CONNECTOR
23 1 4000467 HOSE CLAMP
24 1 4001250 HOSE
25 1 4001251 COMPRESSOR REAR COVER
26 1 4001252 COMPRESSOR FRONT COVER
27 1 4000316 FLANGED HEAD SCREW
FAN ASSEMBLY (S/No. ►ROBO031400418)
ROBOCUT
McCONNEL
