UNDERCARRIAGE SPECIFICATIONS
Loading Capacity 1.2T
Length 1548mm
Axle to axle length 1192mm
Track height 479.5mm
Crossmember height (from ground) 150mm
Fixed undercarriage width 1260mm
Number of lower rollers per side (per machine) 4 + 4 (8)
Number of upper rollers per side (per machine) 1 + 1 (2)
Track width 230mm
Number of links per side (per machine) 47 + 47 (94)
Chain pitch 72mm
Track tensioner pressure (Max) 150Bar
Total weight 444kg
Hydraulic motor displacement
332cm³
Hydraulic motor pressure (Max) 190Bar
Hydraulic flow rate (Max) 39l/min
Maximum speed 7km/h
Operating temperature range
-10/+40°C
Maximum operating humidity 95%
Brake release pressure range 12-16Bar
Maximum gradeability 114%
