61
REF. QTY. PART No. DESCRIPTION
FLAILHEAD ASSEMBLY (Continued)
37 1 4000217 SCREW
38 1 4000218 NUT
39 1 4000219 SPRING
(Item now obsolete use Spring 4000749)
1 4000749 SPRING
(Not compatible with Spring Bracket 4000204)
40 1 9163003 LOCK NUT
41 1 4000220 FLANGED NUT
42 8 9163005 LOCK NUT
43 1 4000221 LOCK NUT
44 11 9100105 WASHER
45 2 9100106 WASHER
46 2 4000253 WASHER
47 2 4000222 WASHER
48 1 9100206 SPRING WASHER
49 1 4000254 WASHER
50 1 9100105 WASHER
51 1 4000223 GREASER
52 2 4000224 GREASER
53 2 4000225 BEARING
54 2 4000226 ROLLER BEARING
55 1 4000227 TAPERLOCK BUSH
56 2 4000023 CIRCLIP
57 1 4000228 RETAINING RING
58 2 4000024 CIRCLIP
59 1 4000229 MOTOR
60 1 4000230 CONICAL BUSH
61 1 4000231 PULLEY
62 1 4000232 PULLEY
63 3 4000233 TRAPEZOIDAL TOOTHED BELT
64 1 4000234 OILSEAL
65 2 4000235 OIL SEAL
66 2 4000236 GUIDE FOR OIL SEAL
67 1 4000237 BUSH
68 1 4000238 WASHER
69 1 4000757 LOCK NUT
70 1 4001094 EXPANSION VESSEL
4000716 SEAL KIT FOR MOTOR 4000229
When replacing the now obsolete early type Spring 4000219 with the later type Spring 4000749
the early type Bracket 4000204 must also be replaced with later type bracket 4000338.
FLAILHEAD ASSEMBLY– Robocut S/No: ►ROBO021400399
ROBOCUT FLAILHEAD
