McConnel RoboCut - Page 126

73
REF. QTY. PART No. DESCRIPTION
HYDRAULIC ASSEMBLY
Builds - Serial No. 1301213020400 ►
1 1 4001389 HYDRAULIC HOSE
2 1 4001390 HYDRAULIC HOSE
3 1 4000765 HYDRAULIC HOSE
4 1 4000766 HYDRAULIC HOSE
5 1 4000767 HYDRAULIC HOSE
6 3 7315797 CONNECTOR
7 2 4001430 CONNECTOR
8 3 4000748 CONNECTOR
9 2 4000587 CONNECTOR
10 1 4000133 CONNECTION
11 1 4000139 PLUG
12 2 4000136 CONNECTION
13 2 4000137 PLUG
14 1 4000132 CONNECTION
15 1 4000140 PLUG
16 1 4000135 CONNECTION
17 1 4000668 PLUG
18 1 4000229 MOTOR
19 1 4000186 HYDRAULIC RAM
20 1 4001431 CONNECTOR
4000716 SEAL KIT FOR MOTOR 4000229
4001297 SEAL KIT FOR HYDRAULIC RAM 4000186
HYDRAULIC
A
SSEMBLY – Robocut S/No: ROBO021400400 ►
ROBOCUT FLAILHEAD
–
Head S/No: 1301213020400
►
McCONNEL
