12
Display LCD - Features & Functions
Area 1. - Warning & Error Codes
Area 2. - Coolant Gauge
Area 3. - Menu Access Buttons
Home Screen
Insert ignition key and turn clockwise to the first position; the display will switch on showing the
‘home screen’. The features displayed will be as shown below;
1. – Battery / Alternator Warning
2. – Engine Oil Pressure warning
3. – Parking Brake Warning
4. – Engine Stop
5. – Pre-Heat Plugs (*)
(*) Only applicable to machines fitted with optional heater plugs.
Service Menu
The service screen displays the number of hours the
machine has been used and the number of hours
remaining before the next service is due.
The service warning symbol will be displayed when
the pre-set service interval has been reached, the
machine must now be serviced, (refer to maintenance
section for details), and the service counter reset.
When the correct service work has been performed
contact McConnel Service on +44 (0)1584 875 848 to
obtain a 4 digit code needed to reset the counter.
Note: the service warning symbol will continue to flash
each time the engine is started until the service
counter has been reset.
