McConnel RoboCut - Page 56

3
REF. QTY. PART No. DESCRIPTION
CHASSIS ASSEMBLY
1 2 4000006 DRIVE SPROCKET
2 2 4000263 RUBBER TRACK 250/72/47
3 20 4000352 CYLINDRIC HEAD SCREW
4 20 4000357 KNURLED WASHER
5 1 4000360 RH TRACK DRIVE MOTOR
6 2 4001226 TRACK MOTOR COVER
7 8 4000316 FLANGED HEAD SCREW
8 2 4000011 COVER PLATE
9 2 4000775 TENSIONER COVER
10 1 4000359 LH TRACK DRIVE MOTOR
11 8 4000442 FLANGED HEAD SCREW
12 4 4000744 TRACK BLOCKING
13 2 4000777 SEAL KIT
14 1 4000039 UNDERCARRIAGE HOUSING
15 4 4000010 BUSH
16 4 4000778 SEAL
17 4 4000024 CIRCLIP
18 2 4000005 SPROCKET
19 2 4000004 SPROCKET FORK
20 8 4000353 FLANGED HEAD SCREW
21 4 4000032 ROLL PIN
22 2 4000009 PIN
23 6 4000776 BEARING
24 2 4001224 BOLT KIT (Pack of 5 Bolts)
25 10 4001225 FLANGED NUT
CHASSIS ASSEMBLY
ROBOCUT
McCONNEL
