REF. QTY. PART No. DESCRIPTION
TRACK TENSIONER ASSEMBLIES
1 2 4000782 MECHANICAL TENSIONER
- Comprising of:
2 1 4000783 TENSIONER LEVER
3 1 4000784 SPACER
4 1 4000785 TENSIONER
5 1 4000786 HEX HEAD SCREW
6 1 4000787 NUT
7 1 4000788 NUT
8 1 4000018 LOCKNUT
9 1 4000253 WASHER
10 2 4001227 HYDRAULIC TENSIONER
- Comprising of:
11 1 4000001 TENSIONER ROD
12 1 4000002 TENSIONER CYLINDER
13 1 4000003 TENSIONER CAP
14 1 4000358 BUTTING HEAD FITTING
1 4001301 BLANKING PLUG
(not shown)
15 1 4000012 * VALVE HOUSING
16 1 8650318 BONDED SEAL
17 1 4000030 * O RING
18 1 4000013 * VALVE
19 1 4000014 * SPRING
20 1 4000029 * PERFORATED NUT
21 1 4000008 SPRING
22 1 4000031 WASHER
23 1 4000028 BUSHING
24 1 4000354 GRUB SCREW
25 1 4000018 LOCKNUT
4000348 TRACK TENSIONER VALVE KIT c/o items
