REF. QTY. PART No. DESCRIPTION
RADIATOR COVERS ASSEMBLY
1 1 4000401 RADIATOR BONNET ASSEMBLY
- comprising of:
2 41 4001229 LOCKNUT
3 41 9100102 WASHER
4 1 4000155 CENTRAL LOWER MESH
5 2 4000154 SIDE MESH
6 2 4000107 CYLINDRIC HEAD SCREW
7 2 4000798 WASHER
8 2 4000799 LOCKNUT
9 2 4000112 BONNET FASTENER
10 1 4001230 RADIATOR BONNET
11 1 4000374 CENTRAL UPPER MESH
12 1 4001368 RUBBER SEAL
(not illustrated)
RADIATOR COVERS ASSEMBLY
ROBOCUT
McCONNEL
