31
REF. QTY. PART No. DESCRIPTION
ACTUATOR ASSEMBLY (Early Builds)
1 1 4000057 BRACKET
(
Item discontinued
)
2 1 4000441 COUNTERSUNK HEAD SCREW
3 2 4000442 FLANGED HEAD SCREW
4 1 4000086 ACTUATOR
5 3 4000381 AUTOGRIP NUT
6 4 4000078 WASHER
7 1 4000806 HEX HEAD SCREW
8 4 4000316 FLANGED HEAD SCREW
9 1 4000058 THROTTLE BRACKET
10 1 4000059 ACTUATOR ARM
11 1 4000074 THROTTLE SPRING
12 1 4000060 ACTUATOR SPRING LINKAGE
13 2 4000443 AUTOGRIP NUT
Bracket Part No. 4000057 has been discontinued; replacement of this bracket
now requires the use of Actuator Bracket Conversion Kit (Part No. 4001397)
-
this kit converts the assembly to the same arrangement as current builds.
REF. QTY. PART No. DESCRIPTION
ACTUATOR ASSEMBLY (Current Builds)
1 1 4001408 BRACKET
2 2 4000441 COUNTERSUNK HEAD SCREW
3 2 4000442 FLANGED HEAD SCREW
4 1 4000086 ACTUATOR
5 3 4000380 AUTOGRIP NUT
6 4 4000078 WASHER
7 1 4000806 HEX HEAD SCREW
8 4 4000316 FLANGED HEAD SCREW
9 1 4000058 THROTTLE BRACKET
10 1 4001407 ACTUATOR ARM
11 1 4000074 THROTTLE SPRING
12 1 4000060 ACTUATOR SPRING LINKAGE
13 2 4000443 AUTOGRIP NUT
14 1 4001406 BRACKET
A
CTUATOR ASSEMBLY
ROBOCUT
McCONNEL
