23
Manual No. 4111-0019
May 2015
July 2016
MAINTENANCE
Quarterly Maintenance
• Lubricate the following areas with light-weight
machine oil:
(2)— Lip maintenance prop pivot
(5)— Hold-down pivot/pulley
(6)— Safety leg linkage pivots
(8)— Hold down-to-platform pin
• Lubricate the following areas with white lithium
grease: (zerk fittings)
(1)— Lip hinge area
(3)—Lift arm roller bushing
(4)— Lift arm pivot
(7)— Lip assist pin
Regular maintenance must be performed on a weekly
and quarterly schedule. Follow all safety precautions
Weekly Maintenance
• Operate the dock leveler through the complete
operating cycle to maintain lubrication.
NOTE: To thoroughly inspect the platform hinge area,
put the platform in the full below-dock position.
• Inspect the platform hinge and the lip hinge areas.
The hinge areas must be kept free of dirt and
debris. Build-up of foreign material in the hinge
areas will cause abnormal operation.
Failure to properly lubricate the dock leveler will
cause abnormal operation of the leveler.
