ADJUSTMENTS
Adjust Lift Arm Spring and Lip Assist Spring Tension
1 — Jam Nut
2 — Adjustable Nut
3 — Lip Assist Spring
4— Lift Springs
5 — Lift Spring Bolt
6 — Hold-Down Mechanism
When service under the dock leveler is required,
always lock all electrical disconnects in the OFF
position after raising the platform and engaging
the maintenance prop. Failure to follow these
instructions could result in death or serious injury.
Always stand clear of the dock leveler lip when
working in front of the dock leveler.
The maintenance prop MUST be in the service
position when working under the dock leveler.
For maximum protection, use an OSHA approved
locking device to lock the maintenance prop in
the service position. Only the person servicing
the equipment should have the key to unlock the
maintenance prop.
Failure to follow these instructions could result in
death or serious injury.
Always post safety warnings and barricade the
work area at dock level and ground level to prevent
unauthorized use of the dock leveler before
maintenance is complete. Failure to follow these
instructions could result in death or serious injury.
