Page #16 background imageLoading...
Page #16 background image
16
5. Rotate the VOLUME/ADJUST Control until “Ac-
tion: SOURCE” appears. Refer to figure 17.
6. Then press the OUTPUT 2 / MENU ► Push-
button until the Setup Menu item “SETUP: TRIG1
OUTPUT, Source: _ _ _ _ _ _ _ _ OFF” appears
on the Front Panel Information Display. Refer to
figure 18.
Notes: 1. By default all the Source Inputs are set to
Off.
2. Any combination of Source Inputs from
one to all may be assigned to either Trig-
ger (1 or 2) or both Triggers.
7. Rotate the INPUT Control to select the Tuner as
the source. Refer to figure 18.
8. Rotate the VOLUME/ADJUST Control until
“Source: Tuner ON” appears. Refer to figure 19.
9. Press the EQ BYPASS/SETUP Push-button to exit
the Setup Mode.
Figure 17
SETUP: TRIG1 OUTPUT
Action: SOURCE
Figure 18
SETUP: TRIG1 OUTPUT
Source: Tuner OFF
Figure 19
SETUP: TRIG1 OUTPUT
Source: Tuner ON
Power Control Triggers 1 and 2
By default the Power Control TRIGger 1 and TRIG-
ger 2 Outputs function the same as the MAIN Power
Control Jack, switching On/Off with the C50. Trigger
1 and 2 are also reassignable to activate when the ACC
ON/OFF Push-buttons on the Remote Control are used
or when a given Input or Inputs are selected.
In the first example, the Power Control Trigger 1
Output will be set to function via the Remote Control
ACC Push-buttons.
1. Press and hold the EQ BYPASS/SETUP Push-
button until the Setup Mode is active. Then press
the OUTPUT 2 / MENU ► Push-button until the
Setup Menu item “SETUP: TRIG1 OUTPUT, Ac-
tion: MAIN” appears on the Front Panel Informa-
tion Display. Refer to figure 15.
2. Rotate the VOLUME/ADJUST Control until “Ac-
tion: REMOTE” appears. Refer to figure 16.
3. Press the EQ BYPASS/SETUP Push-button to exit
the Setup Mode.
The second example will use selection of the Tuner
Input to switch the Trigger 1 Output On.
4. Press and hold the EQ BYPASS/SETUP Push-
button until the Setup Mode is active. Then press
the OUTPUT 2 / MENU ► Push-button until the
Setup Menu item “SETUP: TRIG1 Output, Ac-
tion: MAIN” appears on the Front Panel Informa-
tion Display. Refer to figure 15.
Figure 15
SETUP: TRIG1 OUTPUT
Action: MAIN
Figure 16
SETUP: TRIG1 OUTPUT
Action: REMOTE
2. Rotate the VOLUME/ADJUST Control until
“SETUP: PASSTHRU, Source: BALANCED 2”
appears on the Front Panel Alphanumeric Display.
Refer to figure 14.
3. Press the EQ BYPASS/SETUP Push-button to exit
the Setup Mode.
Passthru, con’t
SETUP: PASSTHRU
Source: BALANCED 2
Figure 14
