15
The C52 Default Setting for using Headphones is to
automatically mute all the Output Connectors when
the Headphone Cable Plug is inserted into the C52
Front Panel HEADPHONES Jack. There are three
available settings:
Mute All Outputs
Mute Main Output
Mute No Outputs
6. Rotate the INPUT Control until “SETUP: HEAD-
PHONES, Mute All Outputs ” appears on the
Information Display. Refer to figure 26.
7. Rotate the VOLUME (ADJUST) Control to change
the current HEADPHONES setting from “Mute
All Outputs” to either “Mute Main Output” or
“Mute No Outputs”. Refer to figures 27 and 28.
8. Exit the SETUP Mode by several presses of the
INPUT Control.
The Output Settings provide the ability to change how
the C52 Output 1, Output 2 and Headphones function.
OUTPUT 1 and 2:
By defaut OUTPUT 1 and 2 are set to go On/Off by
using the Front Panel OUTPUT 1 and 2 push-buttons
or by using the OUTPUT 1 and 2 push-buttons on the
Remote Control. If it is desirable to have OUTPUT 1
and/or 2 always On regardless of the OUTPUT 1 and
2 Push-button settings, perform the following:
1. Press and hold in the INPUT Control to enter the
SETUP MODE. Refer to figure 2 on page 13.
2. Rotate the INPUT Control until “SETUP: Out-
puts, (Hold INPUT)” appears on the Information
Display. Refer to figure 21.
3. Press and hold in the INPUT Control until
“SETUP: OUTPUT 1, Switched” appears on the
Display. Refer to figure 22.
4. Rotate the VOLUME (ADJUST) Control to change
from the “Switched” setting to “Unswitched”.
Refer to figure 23.
5. In a similar manner, perform steps 3 and 4 to
change the OUTPUT 2 setting. Refer to figures 24
and 25.
20. To save the new name, press and hold in the IN-
PUT Control until “SETUP: MEDIA BRDG , ON
/ Rename” appears on the Front Panel Information
Display. Refer to figure 20.
21. Exit the SETUP Mode by several presses of the
INPUT Control.
Note: For convenience, an “Input Assignment Chart”
on a separate sheet “Mc5A/5B” has been pro-
vided to keep track of changes.
Setup, con’t
Figure 15
RENAME: BAL 1
>MEDIA <
Figu re 16
RENAME: BAL 1
>MEDIA B <
Figu re 17
RENAME: BAL 1
>MEDIA BR <
Figu re 18
RENAME: BAL 1
>MEDIA BRD <
Figure 19
RENAME: BAL 1
>MEDIA BRDG <
Figure 20
SETUP: MEDIA BRDG
On / Rename
Output Settings
Figure 21
SETUP: Outputs
(Hold INPUT)
Figure 23
SETUP: OUTPUT 1
Unswitched
Figure 22
SETUP: OUTPUT 1
Switched
Figure 25
To Next Page
